| Nama Wahi | AM-1024768Y2TZQW-A1H |
| Waitohu | AMPIRE |
| Rahi | 10.4 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel model | AM-1024768Y2TZQW-A1H |
| panel size | 10.4" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1024(RGB)×768, XGA, 123PPI |
| pixel format | RGB Vertical Stripe |
| display area | 211.2(W)×158.4(H) mm |
| bezel opening | 213.2(W)×160.4(H) mm |
| outline size | 236(W)×174.3(H) ×10.4(D) mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 1000 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 30 (Typ.)(Tr+Td) |
| display colors | 16.2M |
| lamp type | WLED , 30K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | TBD |
| application | Industrial Outdoor High Brightness |
| signal interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
