| Nama Wahi | AM-1024768V1TZQW-A0H |
| Waitohu | AMPIRE |
| Rahi | 8.4 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM-1024768V1TZQW-A0H |
| diagonal size | 8.4 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 152PPI |
| configuration | RGB Vertical Stripe |
| active area | 170.8(H)×128.1(V) mm |
| outline dim. | 203(H)×145.5(V) ×8(D) mm |
| bezel area | 174.15(H)×131.2(V) mm |
| treatment | - |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | IPS, Normally Black, Transmissive |
| support color | 16.7M |
| light source | WLED [6S6P] , 50K hours , With LED Driver |
| weight | - |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
