| Nama Wahi | AM-1024768TTMQW-T00H |
| Waitohu | AMPIRE |
| Rahi | 10.4 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM-1024768TTMQW-T00H |
| diagonal size | 10.4 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 123PPI |
| configuration | RGB Vertical Stripe |
| active area | 211.2(H)×158.4(V) mm |
| outline dim. | 236(H)×176.9(V) ×7.9(D) mm |
| bezel area | 214.8(H)×162.0(V) mm |
| treatment | Antiglare |
| luminance | 280 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| view direction | 6 o'clock |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 75/75/75/75 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K/16.7M |
| light source | WLED [4 strings] , 30K hours , With LED Driver |
| weight | 290g (Max.) |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | 4-wire Resistive Touch |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| LM-CJ53-22NAK | SANYO | 10.4 | 640×480 |
| LQ10D341 | SHARP | 10.4 | 640×480 |
| LQ10D368 | SHARP | 10.4 | 640×480 |
| LQ10D41 | SHARP | 10.4 | 640×480 |
| LTM104V3-100 | Samsung | 10.4 | 640×480 |
| PD104SL7 | E Ink | 10.4 | 800×600 |
