| Nama Wahi | AM-1024768FCTMQW-T00H |
| Waitohu | AMPIRE |
| Rahi | 10.4 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM-1024768FCTMQW-T00H |
| diagonal size | 10.4 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 123PPI |
| configuration | RGB Vertical Stripe |
| active area | 210.4(H)×157.8(V) mm |
| outline dim. | 238.6(H)×175.8(V) mm |
| luminance | 280 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 14/11 (Typ.)(Tr/Td) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| operating mode | Normally Black, Transmissive |
| support color | 262K/16.2M 57% NTSC |
| light source | WLED , 30K hours , With LED Driver |
| weight | - |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | PCAP |
| interface type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
