| Nama Wahi | AA084VB01 |
| Waitohu | Mitsubishi |
| Rahi | 8.4 |
| Taupānga | IA |
| Whakatau | 640×480 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 150:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | Mitsubishi |
| panel model | AA084VB01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.4 inch |
| resolution | 640(RGB)×480 , VGA |
| display mode | TN, Normally White, Transmissive |
| active area | 170.88×128.16 mm |
| outline | 221×152.4 mm |
| surface | Antiglare (Haze 12%) |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 150:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 20/30 (Typ.)(Tr/Td) |
| viewing angle | 60/60/50/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.)(VCC) |
| application | IA |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AA084SB01 | Mitsubishi | 8.4 | 800×600 |
| AA084SC01 | Mitsubishi | 8.4 | 800×600 |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AA084VB02 | Mitsubishi | 8.4 | 640×480 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA084VD02 | Mitsubishi | 8.4 | 640×480 |
| AA084VG01 | Mitsubishi | 8.4 | 640×480 |
| AA084XB11 | Mitsubishi | 8.4 | 1024×768 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| KCS057QV1BR-G21 | Kyocera | 5.7 | 320×240 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LM32004 | SHARP | 5.7 | 320×240 |
| M190EG01 V3 | AUO | 19.0 | 1280×1024 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| TM150TDS50 | Tianma | 15.0 | 1024×768 |
| TX18D200VM0EAA | KOE | 7.0 | 1920×1080 |
| TX26D12VM0APA | KOE | 10.4 | 800×600 |
| UG-9639TSWEG03 | WiseChip | 0.82 | 96×39 |
