ZJ043NA-01M


Waitohu
Innolux
Rahi
4.3
Taupānga
Video Door Phone MP3
Whakatau
480×272
Te tito
LCM,   a-Si TFT-LCD
Tirohanga
CR
500:1
Nga Tae
16.7M
Whakamuri
8S1P
Atanga
In Stock
19139
Whakatakotoranga

Nama Wahi ZJ043NA-01M
WaitohuInnolux
Rahi4.3
TaupāngaVideo Door Phone MP3
Whakatau480×272
Te titoLCM,   a-Si TFT-LCD
Tirohanga
CR500:1
Nga Tae16.7M
Whakamuri8S1P
Atanga
manufacturerInnolux
model nameZJ043NA-01M
screen size4.3 inch
screen typeLCM,   a-Si TFT-LCD
pixel number480(RGB)×272   (WQVGA)  128PPI
arrangementRGB Vertical Stripe
active area(mm)95.04 × 53.856 (H×V)
outline(mm)105.5 × 67.2 (H×V×D)
bezel area(mm)-
treatmentAntiglare
luminance400 cd/m² (Typ.)
contrast ratio500 : 1 (Typ.) (TM)
viewing angle70/70/50/70 (Typ.)(CR≥10)
response10/15 (Typ.)(Tr/Td) ms
good view at-
work modeTN, Normally White, Transmissive
color depth16.7M   50% NTSC
backlight8S1P WLED , No Driver
mass43.3g (Typ.)
used forVideo Door Phone MP3 PMP
refresh rate-
touchscreenWithout
Storage Temp.: -30 ~ 80 °C    Operating Temp.: -10 ~ 70 °C
