| Nama Wahi | WG12232D-YYK-VA |
| Waitohu | Winstar |
| Rahi | 1.9 |
| Taupānga | Industrial Instrumen |
| Whakatau | 122×32 |
| Te tito | STN-LCD , LCM |
| Tirohanga | |
| CR | 3:1 |
| Nga Tae | Monochrome |
| Whakamuri | YG-LED |
| Atanga | 8-bit |
| panel brand | Winstar |
| panel size | 1.9" |
| resolution | 122×32, 67PPI |
| display area | 45.72(W)×11.97(H) mm |
| outline size | 59(W)×29.3(H) ×5.5(D) mm |
| brightness | - |
| viewing angle | 30/30/20/40 (Typ.)(CR≥2) |
| best view on | 12 o'clock |
| display colors | Monochrome |
| frequency | - |
| panel weight | - |
| signal interface | 8-bit 6800 parallel , 18 pins Pad |
| input voltage | 5.0V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | WG12232D-YYK-VA |
| panel type | STN-LCD , LCM |
| pixel format | Rectangle |
| bezel opening | 52.0(W)×15.0(H) mm |
| surface | - |
| contrast ratio | 3:1 (Typ.) (TM) |
| display mode | STN, Yellow/Green (Positive), Transflective |
| response time | 100/100 (Typ.)(Tr/Td) |
| lamp type | YG-LED , 100K hours , With LED Driver |
| touch screen | Without |
| application | Industrial Instruments & Meters |
