| Nama Wahi | WG12232D-YYH-V |
| Waitohu | Winstar |
| Rahi | 1.9 |
| Taupānga | Industrial Instrumen |
| Whakatau | 122×32 |
| Te tito | LCM , STN-LCD |
| Tirohanga | |
| CR | 3:1 |
| Nga Tae | Monochrome |
| Whakamuri | YG-LED |
| Atanga | 8-bit |
| manufacturer | Winstar |
| screen size | 1.9 inch |
| pixel number | 122×32 67PPI |
| active area(mm) | 45.72 × 11.97 (H×V) |
| bezel area(mm) | 52.0 × 15 (H×V) |
| luminance | - |
| viewing angle | 30/30/20/40 (Typ.)(CR≥2) |
| good view at | 6 o'clock |
| color depth | Monochrome |
| mass | - |
| refresh rate | - |
| signal type | 8-bit 6800 parallel , 18 pins Pad |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | WG12232D-YYH-V |
| screen type | LCM , STN-LCD |
| arrangement | Rectangle |
| outline(mm) | 59 × 29.3 × 5.5 (H×V×D) |
| treatment | - |
| contrast ratio | 3 : 1 (Typ.) (TM) |
| response | 100/100 (Typ.)(Tr/Td) ms |
| work mode | STN, Yellow/Green (Positive), Transflective |
| backlight | YG-LED , 100K hours , With LED Driver |
| used for | Industrial Instruments & Meters |
| touchscreen | Without |
