| Nama Wahi | WF39BTZASDNN0 |
| Waitohu | Winstar |
| Rahi | 3.9 |
| Taupānga | Industrial Stretched |
| Whakatau | 480×128 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| panel brand | Winstar |
| panel model | WF39BTZASDNN0 |
| panel size | 3.9" (1/2 cut of 4.3") |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 480×128(RGB), 128PPI |
| pixel format | RGB Horizontal Stripe |
| display area | 95.04(W)×25.34(H) mm |
| bezel opening | 97.04(W)×27.34(H) mm |
| outline size | 105.5(W)×37(H) ×3.25(D) mm |
| surface | Antiglare |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 75/75/75/75 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 6 o'clock |
| response time | - |
| display colors | 16.7M |
| lamp type | WLED , Without Driver |
| frequency | - |
| touch screen | Without |
| panel weight | - |
| application | Industrial Stretched Bar LCD |
| signal interface | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
