| Nama Wahi | WF39BTLASDNN0 |
| Waitohu | Winstar |
| Rahi | 3.9 |
| Taupānga | Industrial Stretched |
| Whakatau | 480×128 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | Winstar |
| diagonal size | 3.9 inch (1/2 cut of 4.3") |
| pixel format | 480×128(RGB) 128PPI |
| active area | 95.04(H)×25.34(V) mm |
| bezel area | 97.04(H)×27.34(V) mm |
| luminance | 500 cd/m² (Typ.) |
| view direction | 6 o'clock |
| viewing angle | - |
| support color | 16.7M |
| weight | - |
| frame rate | - |
| interface type | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | WF39BTLASDNN0 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Horizontal Stripe |
| outline dim. | 105.5(H)×37(V) ×3.25(D) mm |
| treatment | Antiglare |
| contrast ratio | 500:1 (Typ.) (TM) |
| response time | - |
| operating mode | TN, Normally White, Transmissive |
| light source | WLED , W/O Driver |
| designed for | Industrial Stretched Bar LCD |
| touch panel | Without |
