Nama Wahi | WEO128128BL |
Waitohu | Winstar |
Rahi | 1.2 |
Taupānga | Wearable Round Displ |
Whakatau | 128×128 |
Te tito | PM-OLED , OLED |
Tirohanga | |
CR | |
Nga Tae | Mono(Yellow) |
Whakamuri | self |
Atanga | 8-bit |
brand | Winstar |
diagonal size | 1.2 inch |
pixel format | 128×128 108PPI |
active area | 30(H)×30(V) mm |
view direction | Symmetry |
viewing angle | - |
support color | Mono(Yellow) |
weight | - |
frame rate | - |
d-ic detail | COG Built-in SSD1327ZB |
interface type | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
power supply | 3.0V (Typ.) |
environment | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
model | WEO128128BL |
type | PM-OLED , OLED |
configuration | Rectangle |
outline dim. | 36.98(H)×41.23(V) ×2.25(D) mm |
response time | - |
operating mode | - |
light source | self |
designed for | Wearable Round Display |
touch panel | Without |
