| Nama Wahi | WEO009616AW |
| Waitohu | Winstar |
| Rahi | 0.84 |
| Taupānga | Wearable |
| Whakatau | 96×16 |
| Te tito | PM-OLED , OLED |
| Tirohanga | |
| CR | |
| Nga Tae | Mono(White) |
| Whakamuri | self |
| Atanga | I²C |
| brand | Winstar |
| diagonal size | 0.84 inch |
| pixel format | 96×16 115PPI |
| active area | 21.104(H)×3.504(V) mm |
| bezel area | 23.104(H)×5.504(V) mm |
| view direction | Symmetry |
| viewing angle | - |
| support color | Mono(White) |
| weight | - |
| frame rate | - |
| d-ic detail | COG Built-in SSD1306BZ |
| interface type | I²C , 14 pins FPC |
| power supply | 3.0V (Typ.) |
| environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
| model | WEO009616AW |
| type | PM-OLED , OLED |
| configuration | Rectangle |
| outline dim. | 29.1(H)×9.2(V) ×1.46(D) mm |
| treatment | - |
| response time | - |
| operating mode | - |
| light source | self |
| designed for | Wearable |
| touch panel | Without |
