| Nama Wahi | WEO001602GW |
| Waitohu | Winstar |
| Rahi | 2.3 |
| Taupānga | Instruments & Me |
| Whakatau | 5×8 |
| Te tito | OLED , PM-OLED |
| Tirohanga | |
| CR | 2000:1 |
| Nga Tae | Mono(White) |
| Whakamuri | self |
| Atanga | 8-bit |
| manufacturer | Winstar |
| model name | WEO001602GW |
| screen size | 2.3 inch |
| screen type | OLED , PM-OLED |
| char number | 16 characters × 2 lines 7PPI |
| char format | 5×8 dots |
| char pitch(mm) | 3.55×5.95 (H×V) |
| char size(mm) | 2.97×5.57 (H×V) |
| active area(mm) | 56.22 × 11.52 (H×V) |
| outline(mm) | 79 × 44 × 9.67 (H×V×D) |
| bezel area(mm) | 58.22 × 13.52 (H×V) |
| treatment | - |
| luminance | - |
| contrast ratio | 2000 : 1 (Typ.) (TM) |
| viewing angle | 88/88/88/88 |
| response | 0.01 (Typ.) ms |
| good view at | Symmetry |
| work mode | - |
| color depth | Mono(White) |
| backlight | self |
| mass | - |
| used for | Instruments & Meters |
| refresh rate | - |
| touchscreen | Without |
| driver ic list | Built-in COG SSD1311M1Z |
| signal type | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 16 pins Pad |
| voltage supply | 3.3/5.0V (Typ.)(VDD) |
