| Nama Wahi | WEH000802AR |
| Waitohu | Winstar |
| Rahi | 1.2 |
| Taupānga | Instruments & Me |
| Whakatau | 5×8 |
| Te tito | PM-OLED, OLED |
| Tirohanga | |
| CR | |
| Nga Tae | Mono(Red) |
| Whakamuri | self |
| Atanga | CPU/SPI |
| brand | Winstar |
| model | WEH000802AR |
| diagonal size | 1.2 inch |
| type | PM-OLED, OLED |
| char format | 5×8 dots |
| font size | 2.96×5.56 mm |
| font pitch | 3.6×6.3 mm |
| active area | 28.16(H)×11.89(V) mm |
| outline dim. | 58(H)×32(V) ×10(D) mm |
| bezel area | 38(H)×16(V) mm |
| treatment | - |
| view direction | Symmetry |
| response time | - |
| viewing angle | - |
| operating mode | - |
| support color | Mono(Red) |
| light source | self |
| weight | - |
| designed for | Instruments & Meters |
| frame rate | - |
| touch panel | Without |
| d-ic detail | COB Built-in WS0010 |
| interface type | CPU/SPI , 16 pins Pad |
| power supply | 5.0V (Typ.) |
