| Nama Wahi | VLT270-SBL-FHD-168 |
| Waitohu | Vitrolight |
| Rahi | 24.4 |
| Taupānga | Digital Signage Stre |
| Whakatau | 1920×540 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | Vitrolight |
| panel model | VLT270-SBL-FHD-168 |
| panel size | 24.4" (1/2 cut of 27.0") |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×540, 81PPI |
| pixel format | RGB Vertical Stripe |
| display area | 597.6(W)×168(H) mm |
| bezel opening | - |
| outline size | 630(W)×200(H) mm |
| surface | - |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | - |
| response time | 3.8 (Typ.)(G to G) |
| display colors | 16.7M 72% NTSC |
| lamp type | WLED |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | - |
| application | Digital Signage Stretched Bar LCD |
| signal interface | LVDS (2 ch, 8-bit) Connector |
| environment | Operating Temp.: 0 ~ 50 °C ; - |
