Innolux V850DK1-KD1 Rev.J2 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


V850DK1-KD1 Rev.J2

V850DK1-KD1 Rev.J2
V850DK1-KD1 Rev.J2
V850DK1-KD1 Rev.J2 thumb V850DK1-KD1 Rev.J2 thumb
Waitohu
Innolux
Rahi
85
Taupānga
LCTV
Whakatau
3840×2160
Te tito
LCM
Tirohanga
600
CR
5000:1
Nga Tae
1.07B
Whakamuri
WLED
Atanga
V-by-One
In Stock
500
Whakatakotoranga

Nama Wahi V850DK1-KD1 Rev.J2
WaitohuInnolux
Rahi85
TaupāngaLCTV
Whakatau3840×2160
Te titoLCM
Tirohanga600
CR5000:1
Nga Tae1.07B
WhakamuriWLED
AtangaV-by-One
panel brandINNOLUX
panel modelV850DK1-KD1 Rev.J2
panel type a-Si TFT-LCD , LCM
panel size85 inch
resolution3840(RGB)×2160 , UHD
display modeSuper MVA, Normally Black, Transmissive
active area1872×1053 mm
outline1902.6×1083.6×53.8 mm
surfaceAntiglare (Haze 1%), Hard coating (3H)
brightness600 cd/m² (Typ.)
contrast ratio5000:1 (Typ.)
display colors1.07B (8-bit + Hi-FRC), CIE193186%
response time6.5 (Typ.)(G to G)
viewing angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frequency120Hz
lamp typeWLEDEmbedded (LED Driver)
signal interfaceV-by-One 16 lane, 97 pins
input voltage12.0V (Typ.)
applicationLCTV
