V650HP1-LS6 Rev.E

V650HP1-LS6 Rev.E
V650HP1-LS6 Rev.E
V650HP1-LS6 Rev.E
V650HP1-LS6 Rev.E thumb V650HP1-LS6 Rev.E thumb V650HP1-LS6 Rev.E thumb
Waitohu
Innolux
Rahi
65
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
350
CR
5000:1
Nga Tae
1.07B
Whakamuri
WLED
Atanga
LVDS
In Stock
10895
Whakatakotoranga

Nama Wahi V650HP1-LS6 Rev.E
WaitohuInnolux
Rahi65
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga350
CR5000:1
Nga Tae1.07B
WhakamuriWLED
AtangaLVDS
panel brandCHIMEI INNOLUX
panel modelV650HP1-LS6 Rev.E
panel type a-Si TFT-LCD , LCM
panel size65 inch
resolution1920(RGB)×1080 , FHD
display modeSuper MVA, Normally Black, Transmissive
active area1428.48×803.52 mm
outline1450.5×828.52×30.8 mm
surfaceAntiglare (Haze 1%), Hard coating (3H)
brightness350 cd/m² (Typ.)
contrast ratio5000:1 (Typ.)
display colors1.07B (8-bit + Hi-FRC), CIE193172%
response time6.5 (Typ.)(G to G)
viewing angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frequency120Hz
lamp type4 stringsWLEDEmbedded (LED Driver)
signal interfaceLVDS (4 ch, 10-bit), 102 pins
input voltage12.0V (Typ.)
applicationLCTV
