| Nama Wahi | V580DK2-LD1 |
| Waitohu | Innolux |
| Rahi | 58 |
| Taupānga | PID |
| Whakatau | 3840×2160 |
| Te tito | LCM |
| Tirohanga | 1000 |
| CR | 4000:1 |
| Nga Tae | 1.07B |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | CHIMEI INNOLUX |
| panel model | V580DK2-LD1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 58 inch |
| resolution | 3840(RGB)×2160 , UHD |
| display mode | Super MVA, Normally Black, Transmissive |
| active area | 1270.08×721.44 mm |
| outline | 1309.5×767×60.2 mm |
| surface | Antiglare (Haze 1%), Hard coating (3H) |
| brightness | 1000 cd/m² (Typ.) |
| contrast ratio | 4000:1 (Typ.) |
| display colors | 1.07B (8-bit + Hi-FRC), CIE193172% |
| response time | 9.5 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (8 ch, 10-bit), 122 pins |
| input voltage | 12.0V (Typ.) |
| application | PID |
