| Nama Wahi | V236BJ1-LE2 Rev.CA |
| Waitohu | Innolux |
| Rahi | 23.6 |
| Taupānga | TV Sets |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | Innolux |
| model | V236BJ1-LE2 Rev.CA |
| diagonal size | 23.6 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1366(RGB)×768 [WXGA] 66PPI |
| configuration | RGB Vertical Stripe |
| active area | 521.471(H)×293.184(V) mm |
| outline dim. | - |
| luminance | - |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 8.5 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| operating mode | AAS, Normally Black, Transmissive |
| support color | 16.7M 72% NTSC |
| light source | WLED |
| weight | - |
| designed for | TV Sets |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| power supply | 12.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
