| Nama Wahi | UV860QUD-N50 |
| Waitohu | BOE |
| Rahi | 86 |
| Taupānga | TV Sets |
| Whakatau | 3840×2160 |
| Te tito | CELL, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 1.07B |
| Whakamuri | No |
| Atanga | V-by-One |
| manufacturer | BOE |
| model name | UV860QUD-N50 |
| screen size | 86 inch |
| screen type | CELL, a-Si TFT-LCD |
| pixel number | 3840(RGB)×2160 (UHD) 51PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 1895.04 × 1065.96 (H×V) |
| outline(mm) | 1913.1 × 1084 × 1.35 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare (Haze 25%) |
| luminance | 0 cd/m² |
| contrast ratio | 1200 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10) |
| response | 8 (Typ.)(G to G) ms |
| good view at | Symmetry |
| work mode | ADS, Normally Black, Transmissive |
| glass thickness | - |
| transmissivity | 5.4% (Typ.)(with Polarizer) |
| color depth | 1.07B 99% sRGB |
| backlight | No B/L |
| mass | 6.70Kgs (Typ.) |
| used for | TV Sets |
| refresh rate | 60Hz |
| touchscreen | Without |
| driver ic list | Built-in COF 16 source + 16 gate chips |
| signal type | V-by-One 8 lane , Connector 51 pins |
| voltage supply | 12.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
