| Nama Wahi | UG-6464TDDBG01 |
| Waitohu | WiseChip |
| Rahi | 0.60 |
| Taupānga | - |
| Whakatau | 64×64 |
| Te tito | PM-OLED , OLED |
| Tirohanga | |
| CR | 10000:1 |
| Nga Tae | 65K |
| Whakamuri | self |
| Atanga | 4-wire |
| panel brand | WiseChip |
| panel size | 0.60" |
| resolution | 64(RGB)×64, 151PPI |
| display area | 10.73(W)×10.73(H) mm |
| outline size | 15(W)×17.5(H) ×1.3(D) mm |
| brightness | 200 cd/m² (Typ.) |
| viewing angle | - |
| best view on | Symmetry |
| display colors | 65K 60% NTSC |
| frequency | - |
| driver ic | COG Built-in SSD1357 |
| panel weight | 0.66±0.06g |
| signal interface | 4-wire SPI , 20 pins FPC |
| input voltage | 3.0/12.0V (Typ.)(VDD/VCC) |
| environment | Operating Temp.: -40 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| panel model | UG-6464TDDBG01 |
| panel type | PM-OLED , OLED |
| pixel format | RGB Vertical Stripe |
| bezel opening | 11.73(W)×11.73(H) mm |
| surface | - |
| contrast ratio | 10000:1 (Typ.) (TM) |
| display mode | - |
| response time | - |
| lamp type | self , 10K hours |
| touch screen | Without |
| application |
| SVGA060SC | OLiGHTEK | 0.60 | 800×600 |
