| Nama Wahi | TX11D201VM0BAA |
| Waitohu | KOE |
| Rahi | 4.2 |
| Taupānga | Automotive Display |
| Whakatau | 480×272 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | KOE |
| model | TX11D201VM0BAA |
| diagonal size | 4.2 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 480(RGB)×272 [WQVGA] 131PPI |
| configuration | RGB Vertical Stripe |
| active area | 92.88(H)×52.632(V) mm |
| outline dim. | 102.5(H)×69(V) ×15.5(D) mm |
| bezel area | 95.28(H)×55.07(V) mm |
| treatment | Antiglare, Hard coating (2H) |
| luminance | 750 cd/m² (Typ.) |
| contrast ratio | 1500:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | IPS, Normally Black, Transmissive |
| support color | 16.7M 65% NTSC |
| light source | WLED [6S1P] , 50K hours , With LED Driver |
| weight | 97.0g (Typ.) |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | Parallel RGB (1 ch, 8-bit) , 68 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
