| Nama Wahi | TV122WXM-AL0 |
| Waitohu | BOE |
| Rahi | 12.2 |
| Taupānga | Laptop |
| Whakatau | 1280×800 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | BOE |
| model name | TV122WXM-AL0 |
| screen size | 12.2 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1280(RGB)×800 (WXGA) 123PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 262.565 × 164.16 (H×V) |
| outline(mm) | 278.46 × 193.26 × 3.4 (H×V×D) |
| bezel area(mm) | - |
| treatment | Hard coating |
| luminance | 350 cd/m² (Typ.) |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td); 45 (Typ.)(G to G) ms |
| good view at | Symmetry |
| work mode | ADS, Normally Black, Transmissive |
| color depth | 16.7M 50% NTSC |
| backlight | WLED , No Driver |
| outline shape | - |
| used for | Laptop |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
