| Nama Wahi | TV105WUM-AS0 |
| Waitohu | BOE |
| Rahi | 10.5 |
| Taupānga | Pad & Tablet |
| Whakatau | 1200×1920 |
| Te tito | Assembly , a-Si TF |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | 4 |
| Atanga | MIPI |
| manufacturer | BOE |
| screen size | 10.5 inch |
| pixel number | 1200(RGB)×1920 (WUXGA) 215PPI |
| active area(mm) | 141.3 × 226.08 (H×V) |
| bezel area(mm) | - |
| luminance | 480 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 92% DCI-P3 |
| mass | 216g (Typ.) |
| refresh rate | 60Hz |
| signal type | MIPI (4 data lanes) , 34 pins Connector |
| voltage supply | 1.8/5.8/-5.8V (Typ.)(VDD/VSP/VSN) |
| max. ratings | Storage Temp.: -55 ~ 125 °C Operating Temp.: -20 ~ 85 °C |
| model name | TV105WUM-AS0 |
| screen type | Assembly , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 156.18 × 255.06 × 4.44 (H×V×D) |
| treatment | Hard coating |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| response | 25 (Typ.)(Tr+Td) ms |
| work mode | - |
| backlight | 4 strings WLED , No Driver |
| used for | Pad & Tablet |
| touchscreen | PCAP |
