| Nama Wahi | TV101WXM-AG0 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | Pad & Tablet |
| Whakatau | 800×1280 |
| Te tito | Assembly , a-Si TF |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6S6P |
| Atanga | MIPI |
| manufacturer | BOE |
| model name | TV101WXM-AG0 |
| screen size | 10.1 inch |
| screen type | Assembly , a-Si TFT-LCD |
| pixel number | 800(RGB)×1280 (WXGA) 150PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 135.322 × 216.463 (H×V) |
| outline(mm) | 164 × 245.2 (H×V×D) |
| bezel area(mm) | - |
| treatment | Anti Fingerprint, Hard coating (7H) |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | - |
| color depth | 16.7M 57% NTSC |
| backlight | 6S6P WLED , 15K hours , No Driver |
| mass | 300g (Max.) |
| used for | Pad & Tablet |
| refresh rate | 60Hz |
| touchscreen | PCAP |
| signal type | MIPI (4 data lanes) , 51 pins Connector |
| voltage supply | 3.3/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
