| Nama Wahi | TV101WUB-NV0 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | Pad & Tablet |
| Whakatau | 1200×1920 |
| Te tito | a-Si TFT-LCD, CELL |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | MIPI |
| brand | BOE |
| model | TV101WUB-NV0 |
| diagonal size | 10.1 inch |
| type | a-Si TFT-LCD, CELL |
| pixel format | 1200(RGB)×1920 [WUXGA] 225PPI |
| configuration | RGB Vertical Stripe |
| active area | 135.36(H)×216.576(V) mm |
| outline dim. | 140.26(H)×225.346(V) ×0.8(D) mm |
| luminance | 0 cd/m² |
| contrast ratio | 900:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| operating mode | ADS, Normally Black, Transmissive |
| plate thickness | 0.25+0.25 mm |
| transmittance | 5.1% (Typ.)(with Polarizer) |
| support color | 16.7M 71% NTSC |
| light source | No B/L |
| weight | - |
| designed for | Pad & Tablet |
| frame rate | 60Hz |
| touch panel | Without |
| d-ic detail | COG Built-in 2 source chips |
| interface type | MIPI (4 data lanes) , 44 pins Connector |
| power supply | 3.3/9.8/4.8V (Typ.)(VDDI/AVDD/HAVDD) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
