| Nama Wahi | TV070WSM-TL1 |
| Waitohu | BOE |
| Rahi | 7.0 |
| Taupānga | Pad & Tablet |
| Whakatau | 600×1024 |
| Te tito | Assembly , a-Si TF |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6S3P |
| Atanga | MIPI |
| manufacturer | BOE |
| model name | TV070WSM-TL1 |
| screen size | 7.0 inch |
| screen type | Assembly , a-Si TFT-LCD |
| pixel number | 600(RGB)×1024 (WSVGA) 170PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 89.28 × 152.37 (H×V) |
| outline(mm) | 97 × 188.26 (H×V×D) |
| bezel area(mm) | - |
| treatment | Hard coating |
| luminance | 300 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | - |
| color depth | 16.7M 50% NTSC |
| backlight | 6S3P WLED , No Driver |
| mass | 125g (Max.) |
| used for | Pad & Tablet |
| refresh rate | 60Hz |
| touchscreen | On-Cell Touch |
| signal type | MIPI (4 data lanes) , 39 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
