| Nama Wahi | TM150TDSG80 |
| Waitohu | TIANMA |
| Rahi | 15.0 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | TIANMA |
| panel model | TM150TDSG80 |
| panel size | 15.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1024(RGB)×768, XGA, 85PPI |
| pixel format | RGB Vertical Stripe |
| display area | 304.128(W)×228.096(H) mm |
| bezel opening | 307.4(W)×231.3(H) mm |
| outline size | 326.5(W)×253.5(H) ×10(D) mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 12 o'clock |
| response time | 8 (Typ.)(Tr+Td) |
| display colors | 262K/16.7M 60% NTSC |
| lamp type | WLED , 30K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | TBD |
| application | Industrial |
| signal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
