| Nama Wahi | TM121JDSG10 |
| Waitohu | TIANMA |
| Rahi | 12.1 |
| Taupānga | Industrial |
| Whakatau | 1280×800 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | TIANMA |
| model name | TM121JDSG10 |
| screen size | 12.1 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1280(RGB)×800 (WXGA) 124PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 261.12 × 163.2 (H×V) |
| outline(mm) | 278 × 184 × 10.4 (H×V×D) |
| bezel area(mm) | 262.12 × 164.2 (H×V) |
| treatment | Antiglare |
| luminance | 450 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 12/13 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | SFT, Normally Black, Transmissive |
| color depth | 16.7M 40% NTSC |
| backlight | WLED , 50K hours , With LED Driver |
| mass | 440g (Typ.) |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
