| Nama Wahi | TM116VDSP03 |
| Waitohu | TIANMA |
| Rahi | 11.6 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1920×1080 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | 9S6P |
| Atanga | LVDS |
| manufacturer | TIANMA |
| model name | TM116VDSP03 |
| screen size | 11.6 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 190PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 256.32 × 144.18 (H×V) |
| outline(mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| bezel area(mm) | 259.31 × 148.73 (H×V) |
| treatment | Hard coating |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | SFT, Normally Black, Transmissive |
| color depth | 16.7M 70% NTSC |
| backlight | 9S6P WLED , 50K hours , No Driver |
| mass | TBD |
| used for | Industrial Outdoor High Brightness |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltage supply | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
