| Nama Wahi | TM103XDKP05 |
| Waitohu | TIANMA |
| Rahi | 10.3 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | TIANMA |
| model | TM103XDKP05 |
| diagonal size | 10.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×720 200PPI |
| configuration | RGB Vertical Stripe |
| active area | 243.648(H)×91.368(V) mm |
| outline dim. | 259.84(H)×109.3(V) mm |
| bezel area | - |
| treatment | Hard coating, Reflection 5.5% (Typ.) |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| operating mode | SFT, Normally Black, Transmissive |
| support color | 16.7M 75% NTSC |
| light source | WLED [9S4P] , 10K hours , W/O Driver |
| weight | 300g (Typ.) |
| designed for | Outdoor High Brightness Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
