| Nama Wahi | TM103XDHP95 |
| Waitohu | TIANMA |
| Rahi | 10.3 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1920×720 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 11S3P |
| Atanga | |
| manufacturer | TIANMA |
| model name | TM103XDHP95 |
| screen size | 10.3 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1920(RGB)×720 200PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 243.648 × 91.368 (H×V) |
| outline(mm) | 261 × 110.5 × 14.65 (H×V×D) |
| bezel area(mm) | 246.65 × 94.37 (H×V) |
| treatment | Antiglare |
| luminance | 950 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| response | 35 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | SFT, Normally Black, Transmissive |
| color depth | 16.7M 99% sRGB |
| backlight | 11S3P WLED , 10K hours , No Driver |
| mass | TBD |
| used for | Outdoor High Brightness Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
