| Nama Wahi | TM097TDHG04-62 |
| Waitohu | TIANMA |
| Rahi | 9.7 |
| Taupānga | Pad & Tablet Industr |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | TIANMA |
| diagonal size | 9.7 inch |
| pixel format | 1024(RGB)×768 [XGA] 132PPI |
| active area | 196.608(H)×147.456(V) mm |
| bezel area | 200.91(H)×152.27(V) mm |
| luminance | 350 cd/m² (Typ.) |
| view direction | 12 o'clock |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10) |
| support color | 262K 50% NTSC |
| weight | 200g (Typ.) |
| frame rate | 60Hz |
| interface type | LVDS (1 ch, 6-bit) , 30 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TM097TDHG04-62 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 210.2(H)×166.3(V) ×6.5(D) mm |
| treatment | Clear |
| contrast ratio | 500:1 (Typ.) (TM) |
| response time | 20/25 (Typ./Max.)(Tr+Td) |
| operating mode | TN, Normally White, Transmissive |
| light source | WLED [6S6P] , 30K hours , W/O Driver |
| designed for | Pad & Tablet Industrial |
| touch panel | Without |
