| Nama Wahi | TM097TDHG04-02 |
| Waitohu | TIANMA |
| Rahi | 9.7 |
| Taupānga | Pad & Tablet Industr |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 6S6P |
| Atanga | LVDS |
| panel brand | TIANMA |
| panel size | 9.7" |
| resolution | 1024(RGB)×768, XGA, 132PPI |
| display area | 196.608(W)×147.456(H) mm |
| outline size | 210.2(W)×166.3(H) ×5.85(D) mm |
| brightness | 350 cd/m² (Typ.) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10) |
| best view on | 12 o'clock |
| display colors | 262K 50% NTSC |
| frequency | 60Hz |
| panel weight | 200g (Typ.) |
| signal interface | LVDS (1 ch, 6-bit) , 30 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | TM097TDHG04-02 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 200.91(W)×152.27(H) mm |
| surface | Clear |
| contrast ratio | 500:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 20/25 (Typ./Max.)(Tr+Td) |
| lamp type | 6S6P WLED , 30K hours , Without Driver |
| touch screen | Without |
| application | Pad & Tablet Industrial |
