| Nama Wahi | TM080VDSP03 |
| Waitohu | TIANMA |
| Rahi | 8.0 |
| Taupānga | Pad & Tablet |
| Whakatau | 1200×1920 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | 7S3P |
| Atanga | |
| panel brand | TIANMA |
| panel size | 8.0" |
| resolution | 1200(RGB)×1920, WUXGA, 283PPI |
| display area | 107.64(W)×172.224(H) mm |
| outline size | 114.58(W)×184.09(H) ×3.95(D) mm |
| brightness | 390 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 60% NTSC |
| frequency | 60Hz |
| panel weight | TBD |
| input voltage | 3.3V (Typ.)(VCI) |
| environment | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -15 ~ 70 °C |
| panel model | TM080VDSP03 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Hard coating |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | SFT, Normally Black, Transmissive |
| response time | 25 (Typ.)(Tr+Td) |
| lamp type | 7S3P WLED |
| touch screen | Without |
| application | Pad & Tablet |
