| Nama Wahi | TM057QDH01-41 |
| Waitohu | TIANMA |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 640×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 7S3P |
| Atanga | Parallel |
| manufacturer | TIANMA |
| model name | TM057QDH01-41 |
| screen size | 5.7 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 640(RGB)×480 (VGA) 141PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 115.2 × 86.4 (H×V) |
| outline(mm) | 144 × 104.6 × 12.8 (H×V×D) |
| bezel area(mm) | 118.2 × 89.4 (H×V) |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 70/70/70/60 (Typ.)(CR≥10) |
| response | 20 (Typ.)(Tr+Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K 50% NTSC |
| backlight | 7S3P WLED , 50K hours , No Driver |
| mass | 155g |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | Parallel RGB (1 ch, 6-bit) , Connector 33 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
