| Nama Wahi | TM057KDH01-41 |
| Waitohu | TIANMA |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 320×240 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 5S3P |
| Atanga | Parallel |
| panel brand | TIANMA |
| panel model | TM057KDH01-41 |
| panel size | 5.7" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 320(RGB)×240, QVGA, 70PPI |
| pixel format | RGB Vertical Stripe |
| display area | 115.2(W)×86.4(H) mm |
| bezel opening | 118.2(W)×89.4(H) mm |
| outline size | 144(W)×104.6(H) ×12.8(D) mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 70/70/70/60 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 12 o'clock |
| response time | 20 (Typ.)(Tr+Td) |
| display colors | 262K 50% NTSC |
| lamp type | 5S3P WLED , 50K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 160g (Typ.) |
| application | Industrial |
| signal interface | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| ET0570B0DHU | EDT | 5.7 | 640×480 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| KCS057QV1BR-G21 | Kyocera | 5.7 | 320×240 |
| TM057KDH01 | Tianma | 5.7 | 320×240 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| TM057KDH05 | Tianma | 5.7 | 320×240 |
| TM057KDHG03 | Tianma | 5.7 | 320×240 |
| TM057KDHG10 | Tianma | 5.7 | 320×240 |
