| Nama Wahi | TM050RDH03-00 |
| Waitohu | TIANMA |
| Rahi | 5.0 |
| Taupānga | Industrial Portable |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | 7S2P |
| Atanga | Parallel |
| panel brand | TIANMA |
| panel model | TM050RDH03-00 0 Compatible |
| panel size | 5.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 800(RGB)×480, WVGA, 188PPI |
| pixel format | RGB Vertical Stripe |
| display area | 108(W)×64.8(H) mm |
| bezel opening | 111.1(W)×67.9(H) mm |
| outline size | 120.7(W)×75.8(H) ×3.1(D) mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) (TM) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 12 o'clock |
| response time | 20 (Typ.)(Tr+Td) |
| display colors | 16.7M 50% NTSC |
| lamp type | 7S2P WLED , 20K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | TBD |
| application | Industrial Portable Navigation MID UMPC MP3 PMP |
| signal interface | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
