| Nama Wahi | TM050QDH07 |
| Waitohu | Tianma |
| Rahi | 5.0 |
| Taupānga | IA |
| Whakatau | 640×480 |
| Te tito | LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | TIANMA |
| panel model | TM050QDH07 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.0 inch |
| resolution | 640(RGB)×480 , VGA |
| display mode | TN, Normally White, Transmissive |
| active area | 101.568×76.176 mm |
| surface | |
| brightness | |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.7M (6-bit + Dithering), CIE193150% |
| response time | 20 (Typ.)(Tr+Td) |
| viewing angle | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLED |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| input voltage | 3.3/5.0/15.0/-8.2V (Typ.)(VDD/AVDD/VGH/VGL) |
| application | IA |
