| Nama Wahi | TM028HDZG59 |
| Waitohu | TIANMA |
| Rahi | 2.8 |
| Taupānga | Mobile Phone |
| Whakatau | 240×320 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 400:1 |
| Nga Tae | 65K/262K |
| Whakamuri | WLED |
| Atanga | 16-bit |
| brand | TIANMA |
| diagonal size | 2.8 inch |
| pixel format | 240(RGB)×320 [QVGA] 141PPI |
| active area | 43.2(H)×57.6(V) mm |
| luminance | 300 cd/m² (Typ.) |
| view direction | - |
| viewing angle | 70/70/70/58 (Typ.)(CR≥10) |
| support color | 65K/262K 63% NTSC |
| weight | TBD |
| frame rate | - |
| interface type | 16-bit 8080 parallel , 37 pins FPC |
| power supply | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TM028HDZG59 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 50(H)×69.2(V) mm |
| contrast ratio | 400:1 (Typ.) (TM) |
| response time | 25 (Typ.)(Tr+Td) |
| operating mode | TN, Normally White, Transmissive |
| light source | WLED [1S4P] , W/O Driver |
| designed for | Mobile Phone |
| touch panel | Without |
