| Nama Wahi | TCG121XGLPBPNN-AN40-S |
| Waitohu | Kyocera |
| Rahi | 12.1 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | Kyocera |
| panel model | TCG121XGLPBPNN-AN40-S |
| panel size | 12.1" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1024(RGB)×768, XGA, 105PPI |
| pixel format | RGB Vertical Stripe |
| display area | 245.76(W)×184.32(H) mm |
| bezel opening | 249.0(W)×187.5(H) mm |
| outline size | 260.5(W)×203(H) ×10.9(D) mm |
| surface | Antiglare |
| brightness | 780 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | AWV, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 18/12 (Typ.)(Tr/Td) |
| display colors | 262K/16.2M 51% NTSC |
| lamp type | WLED , 50K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 555g |
| application | Industrial Outdoor High Brightness |
| signal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| LQ121X1LH73 | SHARP | 12.1 | 1024×768 |
| LTD121C32S | TOSHIBA | 12.1 | 800×600 |
| LTD121EA3P | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
