| Nama Wahi | TCG121XGLPAPNN-AN20-S |
| Waitohu | Kyocera |
| Rahi | 12.1 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 750:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | Kyocera |
| model | TCG121XGLPAPNN-AN20-S |
| diagonal size | 12.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 105PPI |
| configuration | RGB Vertical Stripe |
| active area | 245.76(H)×184.32(V) mm |
| outline dim. | 260.5(H)×203.4(V) ×10.8(D) mm |
| bezel area | 249.0(H)×187.5(V) mm |
| treatment | Antiglare |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 750:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 18/12 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | AWV, Normally Black, Transmissive |
| support color | 262K/16.2M 50% NTSC |
| light source | WLED , 50K hours , With LED Driver |
| weight | 670g |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| AA121SL12 | Mitsubishi | 12.1 | 800×600 |
| AA121TD02 | Mitsubishi | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LM12S472 | SHARP | 12.1 | 800×600 |
| LMG9980ZWCC-01 | KOE | 12.1 | 800×600 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LTD121EWEK | TOSHIBA | 12.1 | 1280×800 |
| N121I7-L01 | Innolux | 12.1 | 1280×800 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
