| Nama Wahi | TCG070WVLQGPNN-AN40 |
| Waitohu | Kyocera |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 750:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | Kyocera |
| screen size | 7.0 inch |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| active area(mm) | 152.4 × 91.44 (H×V) |
| bezel area(mm) | 154.4 × 93.4 (H×V) |
| luminance | 1000 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 262K/16.2M 50% NTSC |
| mass | 230g |
| refresh rate | 60Hz |
| signal type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| model name | TCG070WVLQGPNN-AN40 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 169.8 × 109.7 × 9.7 (H×V×D) |
| treatment | Antiglare |
| contrast ratio | 750 : 1 (Typ.) (TM) |
| response | 18/12 (Typ.)(Tr/Td) ms |
| work mode | AWV, Normally Black, Transmissive |
| backlight | WLED , 70K hours , With LED Driver |
| used for | Industrial Outdoor High Brightness Automotive Display |
| touchscreen | Without |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| DLC0700OZG-T-1 | Other | 7.0 | 800×480 |
| G070Y3-T01 | Innolux | 7.0 | 800×480 |
| HSD070IFW1-B00 | HannStar | 7.0 | 1024×600 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070T5GC01 | SHARP | 7.0 | |
| LQ070Y5DA02A | SHARP | 7.0 | 800×480 |
| Q070LRE-L81 | Innolux | 7.0 | 1024×600 |
| TCG070WVLBA-A00 | Kyocera | 7.0 | 800×480 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
