| Nama Wahi | TCG070WVLPAANN-AN50-S |
| Waitohu | Kyocera |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K |
| Whakamuri | 2 |
| Atanga | Parallel |
| panel brand | Kyocera |
| panel size | 7.0" |
| resolution | 800(RGB)×480, WVGA, 133PPI |
| display area | 152.4(W)×91.44(H) mm |
| outline size | 165(W)×104.4(H) ×8.5(D) mm |
| brightness | 900 cd/m² (Typ.) |
| viewing angle | 80/80/60/80 (Typ.)(CR≥10) |
| best view on | 12 o'clock |
| display colors | 262K 49% NTSC |
| frequency | - |
| panel weight | 195g (Typ.) |
| signal interface | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | TCG070WVLPAANN-AN50-S |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 154.4(W)×93.4(H) mm |
| surface | Antiglare |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 5/25 (Typ.)(Tr/Td) |
| lamp type | 2 strings WLED , 50K hours , Without Driver |
| touch screen | Without |
| application | Industrial |
