Nama Wahi | T645HB01 V0 |
Waitohu | AUO |
Rahi | 65 |
Taupānga | LCTV |
Whakatau | 1920×1080 |
Te tito | LCM |
Tirohanga | 360 |
CR | 4000:1 |
Nga Tae | 1.07B |
Whakamuri | WLED |
Atanga | LVDS |
panel brand | AUO |
panel model | T645HB01 V0 |
panel type | a-Si TFT-LCD , LCM |
panel size | 65 inch |
resolution | 1920(RGB)×1080 , FHD |
display mode | AMVA3, Normally Black, Transmissive |
active area | 1428.48×803.52 mm |
outline | 1508×878×34.4 mm |
surface | Hard coating (3H) |
brightness | 360 cd/m² (Typ.) |
contrast ratio | 4000:1 (Typ.) |
display colors | 1.07B (10-bit), CIE193172% |
response time | 5.5 (Typ.)(G to G) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 120Hz |
lamp type | WLEDEmbedded (LED Driver) |
signal interface | LVDS (4 ch, 10-bit), 92 pins |
input voltage | 12.0V (Typ.) |
application | LCTV |
