| Nama Wahi | STCG057QVLAM-G02-S |
| Waitohu | Kyocera |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 320×240 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | Kyocera |
| model | STCG057QVLAM-G02-S |
| diagonal size | 5.7 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 320(RGB)×240 [QVGA] 70PPI |
| configuration | RGB Vertical Stripe |
| active area | 115.2(H)×86.4(V) mm |
| outline dim. | 144(H)×104.8(V) ×13.5(D) mm |
| bezel area | 118.4(H)×89.0(V) mm |
| treatment | Glare (Haze 0%) |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) (TM) |
| view direction | - |
| response time | 10/25 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥5) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K 60% NTSC |
| light source | WLED , 40K hours , W/O Driver |
| weight | 158g (Typ.) |
| designed for | Industrial |
| frame rate | - |
| touch panel | Without |
| interface type | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
