| Nama Wahi | ST5461D07-7 |
| Waitohu | CSOT |
| Rahi | 55 |
| Taupānga | TV Sets |
| Whakatau | 3840×2160 |
| Te tito | a-Si TFT-LCD , CELL |
| Tirohanga | |
| CR | 4500:1 |
| Nga Tae | 1.07B |
| Whakamuri | No |
| Atanga | V-by-One |
| panel brand | CSOT |
| panel size | 55" |
| resolution | 3840(RGB)×2160, UHD, 80PPI |
| display area | 1209.6(W)×680.4(H) mm |
| outline size | 1223.5(W)×697.1(H) ×1.34(D) mm |
| brightness | 0 cd/m² |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| glass depth | 0.50+0.50 mm |
| display colors | 1.07B 72% NTSC |
| frequency | 60Hz |
| driver ic | COF Built-in 12 source chips |
| panel weight | 2.65Kgs (Max.) |
| signal interface | V-by-One 8 lane , 51 pins Connector |
| input voltage | 12.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | ST5461D07-7 |
| panel type | a-Si TFT-LCD , CELL |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare (Haze 2%), Hard coating (3H) |
| contrast ratio | 4500:1 (Typ.) (TM) |
| display mode | HVA, Normally Black, Transmissive |
| response time | 5 (Typ.)(G to G) |
| transmissivity | 5.4% (Typ.)(with Polarizer) |
| lamp type | No B/L |
| touch screen | Without |
| application | TV Sets |
