| Nama Wahi | ST5461B03-5 |
| Waitohu | CSOT |
| Rahi | 55 |
| Taupānga | TV Sets |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD , CELL |
| Tirohanga | |
| CR | 4000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | LVDS |
| brand | CSOT |
| diagonal size | 55 inch |
| pixel format | 1920(RGB)×1080 [FHD] 40PPI |
| active area | 1209.6(H)×680.4(V) mm |
| bezel area | - |
| luminance | 0 cd/m² |
| view direction | Symmetry |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| plate thickness | 0.50+0.50 mm |
| support color | 16.7M 72% NTSC |
| weight | 3.50Kgs (Max.) |
| frame rate | 60Hz |
| d-ic detail | COF Built-in 6 source + 8 gate chips |
| interface type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| power supply | 12.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | ST5461B03-5 |
| type | a-Si TFT-LCD , CELL |
| configuration | RGB Vertical Stripe |
| outline dim. | 1223.6(H)×697.1(V) ×1.35(D) mm |
| treatment | Antiglare (Haze 2%), Hard coating (3H) |
| contrast ratio | 4000:1 (Typ.) (TM) |
| response time | 7 (Typ.)(G to G) |
| operating mode | HVA, Normally Black, Transmissive |
| transmittance | 6.5% (Typ.)(with Polarizer) |
| light source | No B/L |
| designed for | TV Sets |
| touch panel | Without |
