| Nama Wahi | SL3229ML-L1 |
| Waitohu | STI |
| Rahi | 28.7 |
| Taupānga | Stretched Bar LCD Di |
| Whakatau | 1366×415 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 16.7M |
| Whakamuri | - |
| Atanga | LVDS |
| panel brand | STI |
| panel model | SL3229ML-L1 |
| panel size | 28.7" (8/15 cut of 32") |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1366(RGB)×415, 49PPI |
| pixel format | RGB Vertical Stripe |
| display area | 697.685(W)×211.961(H) mm |
| bezel opening | - |
| brightness | - |
| contrast ratio | 1200:1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 8 (Typ.)(G to G) |
| display colors | 16.7M |
| lamp type | |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | - |
| application | Stretched Bar LCD Digital Signage |
| signal interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| input voltage | 12.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
