| Nama Wahi | S290AJ1-LE2 Rev.C2 |
| Waitohu | Innolux |
| Rahi | 28.6 |
| Taupānga | Digital Signage Stre |
| Whakatau | 1920×540 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 4500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | Innolux |
| model name | S290AJ1-LE2 Rev.C2 |
| screen size | 28.6 inch (1/2 cut of 32.0") |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1920(RGB)×540 69PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 698.4 × 196.425 (H×V) |
| outline(mm) | 720.8 × 226.3 × 26.8 (H×V×D) |
| bezel area(mm) | 702.4 × 200.4 (H×V) |
| treatment | Antiglare (Haze 2.4%), Hard coating (3H) |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 4500 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 9.5 (Typ.)(G to G) ms |
| good view at | Symmetry |
| work mode | Super MVA, Normally Black, Transmissive |
| color depth | 16.7M 72% NTSC |
| backlight | WLED , 50K hours , With LED Driver |
| mass | 2.40/2.59/2.80Kgs (Min./Typ./Max.) |
| used for | Digital Signage Stretched Bar LCD |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , Connector 51 pins |
| voltage supply | 12.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| S290AJ1-LE1 | Innolux | 29.0 | 1920×540 |
